DP1000-G3 Automated IC Programming System

Model Name : DP1000-G3
DP1000-G3 Automated Chip Programming System is very suitable for mass production in a small office
This item is unavailable for online purchase.



Description

DP1000-G3 automated chip programming system is the third generation of DP1000, which supports different input/output peripherals to provide an overall solution for IC chip programming. It supports most of the IC families, such as EEPROM, NAND/NOR FLASH, MCU, eMMC, and UFS, etc.

The system can embed with 2 sets of NuProgPlus Series programmers to provide up to 32 programming sites with stable quality & high throughput. Additionally, the Auto Teach Feature will automatically adjust the parameter to increase productivity.

Features

    High Throughput

  • The system will be able to perform up to 3,200 UPH.


  High Expansibility

  • Able to embed two sets of NuProgPlus Series programmers (Universal & UFS) to expand up to 32 programming sites.


  Support All IC Families

  • Supported IC: EEPROM, NAND/NOR FLASH, MCU, eMMC, and UFS, etc.
  • Supported IC Package: SOP, SSOP, TSSOP, PLCC, QFN, LQFP, and BGA, etc.



   Adjustable Socket Actuating Kit

  • Adjust socket actuating kits make it easier and quicker to switch to different types of socket adaptors according to the socket size. Therefore, you will not need extra socket actuating kits!



   Support Different Input/Output Peripherals

  • Input/Output: Tube, Tape, and Tray.



   DediProg Auto Teach Feature

  • Proceduralize- Automatically adjust the handler's parameters step by step.
  • Digitalized- Automatically adjust the heights of nozzles.
  • Increase the speed of system adjustment.
  • Self-detection Function- Increase the accuracy & stabilities for nozzles' pick and place.


   Software Supports Work Project

  • Able to create a programming file directly through DediWare according to your programming demands. It allows you to start programming right after loading the project, greatly reducing human errors.



  MES (Manufacturing Execution System)

  • DediProg handlers can apply different MES; the production line via API protocol is easily integrated with their internal server. Work reports can be converted to Excel files as records.


  One Click Project Execution (OPRJ)

  • The OPRJ one-click activation feature enables fool-proof production (machine process and programming project), remote project editing, project preview, and machine qualification management. It can also integrate into MES systems through the API Protocol.


   Report Engine

  • Consolidate and report multiple real-time handler statuses for manufacturing management.



   Optional Ink/Laser Marker/Labeling

  • Consolidate and report multiple real-time handler statuses for manufacturing management.
  • Different colors are available.
  • Ink Marker supports dots, characters & numbers.
  • Laser Marker and Labeling support barcode & QR code.



Optional Accessories

Chip Programmers

♦ NuProgPlus-S8

 NuProgPlus-S16



I/O Peripherals

Automated Taping Machine

 ♦ DP600P Series



Electrical Tape Feeders

 ETF-8mm

 ETF-12mm

 ETF-16mm

 ETF-24mm

 ETF-32mm

 ETF-44mm



Auto Tray Loaders

 Auto Tray-250

 Auto Tray-260

 Auto Tray-350B Series



Manual Tube In/Out Loaders

 MTI-220 (Input)

 MTO-230 (Output)



Others
Ink Marking Systems

 AIM-610 Ink Marker

♦ ALM-610 Laser Marker

 LF-100P2 Label Printer

 ALF-100 Label Feeder



AOI Inspection Systems

 AOI-632 (2D)

 ANS-640-B (2D)

ANS-68X (3D)

ANS-690 (3D)



Auto Parameter Calibration

♦ Auto Teach



Socket Adaptors
