SO8 Connection Adaptor for BBF

Model Name : BBF-CON-8
SO8 Connection Adaptor for BBF
TWD$ 230

Description

SO8 Connection Adaptor for BBF is used to connect Backup Boot flash module-SO8W Socket (2.54mm 2x5) to 1.27mm 2x4 pin header soldered on the application. In this way, the application can work (boot) from Backup Boot Flash Module-SO8W socket directly. Refer to the following Pin Configuration for SO8 connector on the SO8 Connection Adaptor.

SO8 Connector Pin Out

Standard Package
  • SO8W Connection Adaptor for BBF x 1
  • 1.27mm 2x4 SMT male header (10.3mm) x 2
  • 1.27mm 2x4 SMT male header (6.0mm) x 2



Optional
  • Backup Boot Flash Module-SO8W Socket (BBF-8W)
  • 1.27mm 2x4 SMT male header(50pcs) (HD-1)
  • 1.27mm 2x4 Cable with Female Header (CB-24-127)
